小工具 - mysql数据库设计转word

mysql数据库设计转word 介绍

3个类：
一个是数据库类 = SQL()
一个是word文档类 = WORD()
一个是逻辑类 = Main()
先用Main().list()方法找到要跑的表
也可以全部表复制进去
如果一条记录都没有的，不写入表

代码

# -*- coding: utf-8 -*-
import json
from textwrap import indent
import pymysql
from sqlalchemy import create_engine
import docx
import pandas as pd
import numpy as np
class SQL():
    def __init__(self):
        self.ip = "ip"
        self.port = "3306"
        self.port2 = 3306
        self.username = "root"
        self.secret = "secret"
        self.dbname = "dbname"
        # self.tablename = "tablename"
    def connect(self):
        url = 'mysql+pymysql://'+self.username+':'+self.secret+'@'+self.ip+':'+self.port+'/'+self.dbname+'?charset=utf8mb4'
        print(url)
        connect = create_engine(url)
        return connect
    def connect2(self):
        db = pymysql.connect(host=self.ip, user=self.username, password=self.secret, port=self.port2,database=self.dbname)
        cursor = db.cursor()  # 获得指针
        return cursor
    def select(self):
        cursor = self.connect2()
        sql = 'select * from dbname.tablename;'
        cursor.execute(sql)  # 执行
        return cursor
    def all_tables(self):
        cursor = self.connect2()
        sql = "use "+self.dbname+";"
        cursor.execute(sql)  # 执行
        sql = "show tables;"
        cursor.execute(sql)  # 执行
        return list(cursor)
    def select_desc(self, table_name):
        cursor = self.connect2()
        sql = "desc "+table_name+";"
        cursor.execute(sql)  # 执行
        return cursor
    def select_one(self, table_name):
        try:
            cursor = self.connect2()
            sql = "select * from "+table_name+" where id = 1;"
            cursor.execute(sql)  # 执行
            data = cursor.fetchall()
            cols = cursor.description
            data = list(data)
            print('cols')
            print(cols)
            print('cols')
            return data, cols
        except:
            return [], []
class WORD():
    def __init__(self):
        print("")
    def doc(self):
        doc = docx.Document()
        return doc
    def write_table(self, doc, df):
        t = doc.add_table(df.shape[0]+1, df.shape[1])
        # print(df)
        # add the header rows.
        for j in range(df.shape[-1]):
            t.cell(0,j).text = str(df.columns[j])
        # add the rest of the data frame
        for i in range(df.shape[0]):
            for j in range(df.shape[-1]):
                t.cell(i+1,j).text = str(df.values[i,j])
        return
        # save the doc
    def write_dict(self, doc, data):
        data = data.to_dict('records')
        data_str = json.dumps(data,indent=2, default=str,ensure_ascii=False)
        p3 = doc.add_paragraph()
        p3.add_run(data_str)
    def save(self, doc):
        doc.save('./test.docx')
class Main():
    def __init__(self):
        self.table_list = ['user','student']  # 修改需要生成的表
    def list(self):
        table_list = SQL().all_tables()
        table_list_T = []
        for i in table_list:
            table_list_T.append(i[0])
        return table_list_T
    def run(self):
        Sql = SQL()
        Word = WORD()
        doc = Word.doc()  # 新文档
        for i in self.table_list:
            desc_data = Sql.select_desc(i)
            desc_data = pd.DataFrame(data=desc_data)
            one_data, cols = Sql.select_one(i)
            col = []
            for c in cols:
                col.append(c[0])
            one_data = pd.DataFrame(data=one_data, columns=col)
            print(one_data)
            # if one_data==[]:
            if one_data.empty:
                continue
            desc_data["解释"] = ""
            desc_data.columns = ["名字","类型","必填","主键","默认","附加","解释"]
            p3 = doc.add_paragraph()
            p3.add_run(i)
            Word.write_table(doc, desc_data)
            Word.write_dict(doc, one_data)
        Word.save(doc)
if __name__=="__main__":
    # 全部列表，然后要贴到Main()的self.table_list
    # table_list = Main().list()
    # print(table_list)
    Main().run()
